    Migrating large PostgreSQL databases

    Árpád Lajos

    By Árpád Lajos
    April 21, 2020

    Migration

    Photo by Harshil Gudka on Unsplash

    The challenge

    One of our clients has a large and important health-related application. It’s built on an end-of-life Ruby on Rails-based open source framework, heavily customized over the years. They wanted to upgrade to a newer, supported, Java-based open source application a partner organization had developed as a replacement. Both organizations used the old system previously. To do that we would need to migrate all their existing PostgreSQL data from the old system to the new one, retaining important customizations while adapting to the new database schema.

    Although there were many similarities between the old system and the new, the differences were significant enough to require careful study of the database schemas and the migration scripts designed to move the data:

    • There were schema-level differences between our old database and the partner organization’s old database.
    • Even where the two old databases were similar there were differences on the data level, such as different standards, different values in table records, different representation, etc.
    • We had different content, so if a script was working well for their data, it was not necessarily correct for us.
    • There were dynamically generated tables for both old databases and we had to find out how we can convert our current schema elements along with its records to the planned schema elements along with its records.

    We had to understand the differences between our and their old databases. Due to the number of tables and average number of columns, manual comparison between databases was not really an option. We knew that the algorithm of handling the scripts would look like below:

    For each S in Scripts
        Analyze S and understand the intent behind it
        Compute a read-only version of S to avoid write operations
        Execute the read-only version of S
        Analyze the results and find out whether they are different from the expected results
        Convert our read-only version of S to S′, where S′ is compatible with our expectations
        While there are technical issues do
            Fix it
        While end
        Execute S′
    For end


    Understanding these differences was easier said than done. The main problem is that we found it difficult to define our exact expectations. For that purpose we needed a deeper understanding about the databases.

    Entity Relationship Diagram

    We first needed to see an Entity Relationship Diagram (ER diagram or ERD). We used DbVisualizer for this.

    We imported the database into our local RDBMS and then created a database connection by right-clicking Connections in the left menu tree

    then clicking on Create Database Connection and selecting No Wizard

    and filling in the data.

    After that, we double-clicked on the schema we wanted to generate an ER diagram for and clicked on Open Object.

    Finally, we clicked on the References tab and a bird’s-eye view of the ER diagram was generated.

    Then we right-clicked on the diagram and clicked on Export.

    We chose SVG and saved it. After opening the SVG diagram, we saw that the schema was too big to easily analyze, so we dropped the tables we were not specifically interested in in our local copy and generated a new ER diagram. It was super easy and cool. Finally, we were able to see which parts of the other team’s database was old and which was new. We were also able to compare our old database with the new database we were implementing.

    Comparing our databases against their counterparts

    Next we needed to understand what the schema differences were between their old database and our old database to determine what selections in the scripts will not work properly and to determine how we needed to modify it to fit our technical nuances.

    We used Liquibase for this purpose. See Selva’s article on comparing PostgreSQL database schema versions.

    The actual command we used was diff.

    So, we needed to make sure we had a proper setup and then we could run the command. The example output the documentation gives is this:

    Diff Results:
    Reference Database: MYSCHEMA2 @ jdbc:oracle:thin:@localhost:1521:ORCL (Default Schema: MYSCHEMA2)
    Comparison Database: MYSCHEMA @ jdbc:oracle:thin:@localhost:1521:ORCL (Default Schema: MYSCHEMA)
    Compared Schemas: MYSCHEMA2 -> MYSCHEMA
    Product Name: EQUAL
    Product Version: EQUAL
    Missing Catalog(s): NONE
    Unexpected Catalog(s): NONE
    Changed Catalog(s): NONE
    Missing Check Constraint(s): NONE
    Unexpected Check Constraint(s): NONE
    Changed Check Constraint(s): NONE
    Missing Column(s): NONE
    Unexpected Column(s):
         MYSCHEMA.DEPARTMENT.ACTIVE
         MYSCHEMA.SERVICETECH.ACTIVE
         MYSCHEMA.SERVICETECH2.ACTIVE
         MYSCHEMA.SERVICETECH3.ACTIVE
         MYSCHEMA.VIEW1.ACTIVE
         MYSCHEMA.DATABASECHANGELOG.AUTHOR
         MYSCHEMA.DATABASECHANGELOG.COMMENTS
         MYSCHEMA.DATABASECHANGELOG.CONTEXTS
         MYSCHEMA.DATABASECHANGELOG.DATEEXECUTED
         MYSCHEMA.DATABASECHANGELOG.DEPLOYMENT_ID
         MYSCHEMA.DATABASECHANGELOG.DESCRIPTION
         MYSCHEMA.DATABASECHANGELOG.EXECTYPE
         MYSCHEMA.DATABASECHANGELOG.FILENAME
         MYSCHEMA.DATABASECHANGELOG.ID
         MYSCHEMA.DATABASECHANGELOGLOCK.ID
         MYSCHEMA.DEPARTMENT.ID
         MYSCHEMA.SERVICETECH.ID
         MYSCHEMA.SERVICETECH2.ID
         MYSCHEMA.SERVICETECH3.ID
         MYSCHEMA.VIEW1.ID
         MYSCHEMA.DATABASECHANGELOG.LABELS
         MYSCHEMA.DATABASECHANGELOG.LIQUIBASE
         MYSCHEMA.DATABASECHANGELOGLOCK.LOCKED
         MYSCHEMA.DATABASECHANGELOGLOCK.LOCKEDBY
         MYSCHEMA.DATABASECHANGELOGLOCK.LOCKGRANTED
         MYSCHEMA.DATABASECHANGELOG.MD5SUM
         MYSCHEMA.DEPARTMENT.NAME
         MYSCHEMA.SERVICETECH.NAME
         MYSCHEMA.SERVICETECH2.NAME
         MYSCHEMA.SERVICETECH3.NAME
         MYSCHEMA.VIEW1.NAME
         MYSCHEMA.DATABASECHANGELOG.ORDEREXECUTED
         MYSCHEMA.DATABASECHANGELOG.TAG
    Changed Column(s): NONE
    Missing Database Package(s): NONE
    Unexpected Database Package(s): NONE
    Changed Database Package(s): NONE
    Missing Database Package Body(s): NONE
    Unexpected Database Package Body(s): NONE
    Changed Database Package Body(s): NONE
    Missing Foreign Key(s): NONE
    Unexpected Foreign Key(s): NONE
    Changed Foreign Key(s): NONE
    Missing Function(s): NONE
    Unexpected Function(s): NONE
    Changed Function(s): NONE
    Missing Index(s): NONE
    Unexpected Index(s):
         PK_DATABASECHANGELOGLOCK UNIQUE  ON MYSCHEMA.DATABASECHANGELOGLOCK(ID)
         PK_DEPARTMENT UNIQUE  ON MYSCHEMA.DEPARTMENT(ID)
         PK_SERVICETECH UNIQUE  ON MYSCHEMA.SERVICETECH(ID)
         PK_SERVICETECH2 UNIQUE  ON MYSCHEMA.SERVICETECH2(ID)
         PK_SERVICETECH3 UNIQUE  ON MYSCHEMA.SERVICETECH3(ID)
    Changed Index(s): NONE
    Missing Java Class(s): NONE
    Unexpected Java Class(s): NONE
    Changed Java Class(s): NONE
    Missing Java Source(s): NONE
    Unexpected Java Source(s): NONE
    Changed Java Source(s): NONE
    Missing Primary Key(s): NONE
    Unexpected Primary Key(s):
         PK_DATABASECHANGELOGLOCK on MYSCHEMA.DATABASECHANGELOGLOCK(ID)
         PK_DEPARTMENT on MYSCHEMA.DEPARTMENT(ID)
         PK_SERVICETECH on MYSCHEMA.SERVICETECH(ID)
         PK_SERVICETECH2 on MYSCHEMA.SERVICETECH2(ID)
         PK_SERVICETECH3 on MYSCHEMA.SERVICETECH3(ID)
    Changed Primary Key(s): NONE
    Missing Sequence(s): NONE
    Unexpected Sequence(s): NONE
    Changed Sequence(s): NONE
    Missing Stored Procedure(s): NONE
    Unexpected Stored Procedure(s): NONE
    Changed Stored Procedure(s): NONE
    Missing Synonym(s): NONE
    Unexpected Synonym(s): NONE
    Changed Synonym(s): NONE
    Missing Table(s): NONE
    Unexpected Table(s):
         DATABASECHANGELOG
         DATABASECHANGELOGLOCK
         DEPARTMENT
         SERVICETECH
         SERVICETECH2
         SERVICETECH3
    Changed Table(s): NONE
    Missing Trigger(s): NONE
    Unexpected Trigger(s): NONE
    Changed Trigger(s): NONE
    Missing Unique Constraint(s): NONE
    Unexpected Unique Constraint(s): NONE
    Changed Unique Constraint(s): NONE
    Missing View(s): NONE
    Unexpected View(s):
         VIEW1
    Changed View(s): NONE
    Liquibase command 'diff' was executed successfully.


    Of course, we could do this job manually by listing all the tables with psql’s \dt and then checking each of them individually with \d tablename, but if there are many tables, this would take forever.

    Yes, we can write software for this purpose, implementing an algorithm along the lines of

    tables = <execute \dt>
    For each (tables as table) do
        Differences[table] = difference(<execute \d table at db1>, <execute \d table at db2>)
    End For


    however, the algorithm above won’t handle special cases, like tables existing in db1 and not in db2 or vice versa. The algorithm above graciously outsources the arduous task of splitting the rows in both cases by identifying whether a row is a column name, an index, a foreign key, etc. and by identifying the subject of the line (e.g. column name) and finding the matches between the two to a function called difference.

    It is of course implementable, but it would add a considerable amount of work. We should also mention that such a newly developed piece of code would not be well tested yet and we would have to watch out for possible bugs, create unit tests, create a nice UI or file export to ensure that we can analyse the results, and so on. All this work is unnecessary due to the availability of Liquibase and we are only talking about a single command compared to the many here.

    Dynamically generated tables

    In practical terms this means the data our software must manage does not fit a pre-established schema; users create and update new data collection forms regularly. These forms consist of sets of uniquely named questions and text-based answers to those questions. The PostgreSQL JSON data type may seem like a natural fit for such data. However, the original version of the software predates PostgreSQL’s now extensive JSON support. The software version from which we were upgrading stored these data in an Entity-Attribute-Value schema, a database pattern often maligned (justly) by database designers.

    In this version, a single table stored all the answers given for every user-defined question for every case in the system, along with a pointer to the associated question and case. As one might expect, this table grew fairly large, though its principal drawbacks were not its size but rather the large number of joins necessary to process data it contained, and the lack of sufficient data validation. It is possible that the hstore data type would have been a better fit, however, neither programming language support for hstore data nor developer familiarity with it made it an obvious choice at the time. We did use hstore widely in the backend for data manipulation functions that could be contained entirely in SQL.

    Fast forward to newer versions, where this schema has been redesigned. We weren’t involved in the design process and can’t comment on the justification behind this design decision, but the new version creates new tables within the database as needed for each data entry form, and text fields for each question on the form. This reduces the number of joins or aggregations necessary to compile all the data for one form for a single case, but it means creating SQL queries dynamically to create, and later to find, the tables and columns containing data of interest.

    We’ve run our fingers through the data several times, both during and after the migration, and found neither schema variant satisfies our every wish. Both versions store users’ data as text fields, whatever data type they may represent. Some form of data validation at the database level would be very nice, and in the new version where each field has its own column in the database, this is entirely possible, though of course, it would have required more work in the development process. In particular, many questions expect answers taken from a predefined set, for which enumerated types could be a good fit. Of course, stored procedures could conceivably ensure valid data no matter its data type in the schema, but this doesn’t seem like a plausible option in practice. As a further drawback to the new approach, column and table names derive from user-defined data, meaning we need to sanitize user input to create valid PostgreSQL identifiers. This is a tricky process, and difficult to separate entirely into its own module to avoid reimplementing the same intricate logic multiple times.

    JSON data types provide one possible schema alternative, with all entries for one data entry form for a single case stored in a single JSON field, and indeed the PostgreSQL documentation proposes its use in such situations. It’s not entirely clear, though, that this would be a win. We could define new keys within the JSON structure without needing to modify the database schema itself, and with JSON we’d always know exactly what table and field we needed, to find the data we were after, but we’d still need to write queries dynamically in order to pull the desired fields. We could avoid some of the data sanitization necessary to create field names, as the rules for JSON key names are far more permissive than for column names in a proper database table. But, again barring extensive stored procedures, we would still have very limited ability to validate data within the database itself, as JSON supports only a small set of primitive types.

    Putting it all together

    After we acquired the understanding that we needed we were able to work out the migration script according to the algorithm that we outlined at the start of this article.

    This was still a long, labor-intensive task which was done by repeated pair-programming sessions but we were able to reach high enough accuracy. So high that to our great surprise we were able to start the application after the migration process was done.

    Release

    We were able to do the release on a weekend and the three of us moved on to solving problems submitted by beta testers. We called this process “dragon hunting”.


    (Written with help from Selvakumar Arumugam and Joshua Tolley.)
